Single Phase Pump Protection Relay
Product Details:
- Dimension (L*W*H) 66.50 x 70 x 90 Millimeter (mm)
- Warranty 1 Year
- Click to view more
X
Single Phase Pump Protection Relay Price And Quantity
Single Phase Pump Protection Relay Product Specifications
- 66.50 x 70 x 90 Millimeter (mm)
- 1 Year
Single Phase Pump Protection Relay Trade Information
- coimbatore
- Telegraphic Transfer (T/T) Cash in Advance (CID)
- 500 Per Week
- 2 Days
- Yes
- Contact us for information regarding our sample policy
- Western Europe Australia North America South America Eastern Europe Middle East Central America Asia Africa
- All India
- CE
Product Description
1 Pump protection relay [PPRA-4M-1-230V]
| Measuring Parameter | Monitors Over Load (As per NEMA Curve), Over Current, Under Current / Dry run, Locked current, Over voltage, Under Voltage, Phase failure |
| Electrical Connection | 1˜ - 2 |
| Test / Reset | Manual / Auto reset |
| LED Indication | Power ON, Current and Voltage parameter |
| Voltage Measuring Range | 180 to 300V AC (L - N) |
| Power Consumption | 40VA (max) |
| Motor Rated Current Measuring | 1A to 30A |
| Output Contact | Control Output 1 NO Relay Relay Rating 30A@277V AC |
| Accuracy | Current Accuracy ±5% of rated current Voltage Accuracy ±1% of 300V Time Accuracy ±5% ±100msec |
| Functional Specifications | Over Load NEMA class 5, 10, 15, 20, 30 Over Current Ranges 10% - 70% of Ir (Rated Current) Under Current 20% - 80% of Ir (Rated Current) Locked Current / Stall Current Fixed : 300% of Ir (Rated Current) Over Voltage Fixed (280V) Under Voltage Fixed (180V) Phase Loss Yes (<160V) |
| Time Setting | Power ON Delay 1sec (Fixed) Trip Time Delay 0, 2, 4, 6, 8 & 10 sec (Current & Voltage parameters) Auto Reser Time 15min (Current & Voltage parameters) Phase Loss Trip Time Instantaneous (<120ms) |
| Auto Restart Attempts | 3 (Fixed) |
| Mounting | DIN Rail Mount |
| Size | DIN 66.50 x 70 x 90 (H x W x L) |
